Devices are ANSI A156.3 – 2001 Grade 1

Grade 1 Mortise Exit Bar, 48" Device, Exit Only, Delayed Egress Device 15 Seconds, Less Dogging, Satin Aluminum Clear Anodized Finish, Field Reversible

• Device functions: Device ships EO/DT/NL. Field selectable. For TP, K or L remove NL drive screw from device.
• Device lengths: 3' 2'4' to 3' (711mm to 914 mm) Door size 4' 2'10" to 4' (864 mm to 1219 mm) Door size
• Device centerline from finished floor: 39 13/16" (1011 mm) 39 11/16" (1008 mm) with mullion
• Center case dimensions: 8" x 2 3/4" x2 3/8" (203mm x 70mm x 60mm)
• Mechanism case dimensions: 2 1/4" x 2 1/4" (57mm x 57mm)
• Projection: Pushbar neutral – 3 13/16" (97 mm) Pushbar depressed – 3 1/16" (78 mm)
• Fasteners & sex bolts (SNB): Includes screw pack for 1 3/4" (44mm) and 2 1/4" (57mm) thick metal or wood do

Series: 9975 Series Mortise Exit Device
Manufacturer: Von Duprin
Vendor: Allegion
Finish: Satin Aluminum Clear Anodized 628/US28
Function:
Handed:
Grade: Grade 1
Limited Warranty: 1 Year
Fire Rating: No
UL Listing: UL 305
Ansi Code: A156.3 2014
